Exidor Lever Operated Exit Access Device - SIL

The Exidor 325 is an elegant lever operated outside access device Euro profile cylinder supplied separately to allow flexibility of special keying requirements

Features and Specification

• Non-handed
• Powder coated for durability
• Fixings to suit steel, timber, aluminium or uPVC doors
• For doors up to 65mm thick

When locked the lever is disengaged from the mechanism and still rotates therefore preventing unauthorised entry and damage to the unit.

When unlocked the operator, spindle and mechanism engage, allowing the internal hardware?s locking point(s) to be withdrawn from the outside of the door. The lever engaged until the mechanism is re-locked. Releasing the lever returns the internal bolts/latches to the rest position.

Euro Profile Half Cylinder is required (not supplied)- see 9555-502
